Engineering Resilience Against Environmental Stressors
The economic value of grain storage lies in maintaining dry matter and germination rates. Our silo design focuses on mitigating biological and physical risks through robust engineering:
- Airtight Pest Exclusion: A fully sealed shell eliminates oxygen and blocks rodent entry, significantly reducing the need for chemical fumigation.
- Structural Integrity: Designed to withstand Beaufort Scale 12 (120 km/h) winds-equivalent to a Category 1 Hurricane/Typhoon-and seismic accelerations of 0.3g (Zone 4), ensuring stability in extreme weather.
- Active Moisture Control: Integrates a mechanical aeration system to equalize temperature and prevent condensation (sweat), directly combating hot spots and mold formation.
Technical Specifications & Capacity Chart
Each silo is engineered according to ISO and local geotechnical data. Below are standard design parameters:
|
Parameter |
Specification |
Engineering Note |
|---|---|---|
|
Capacity Range |
50 – 10,000 metric tons |
Custom sizes available for large terminals |
|
Diameter |
3 – 20 m |
Janssen Pressure Calculation applied |
|
Height |
5 – 35 m |
Optimized for First-In, First-Out (FIFO) flow |
|
Wall Thickness |
2 – 6 mm |
Calculated per layer (SWG gauge) |
|
Galvanization |
AZ150 / G90 (275 g/m²) |
ASTM A653 / EN 10346 compliant |
|
Access Points |
Side manhole & roof hatch |
OSHA-compliant safety cage |
|
Ventilation |
Mechanical forced ventilation |
Configurable CFM based on grain type |
Material Science & Food Safety Compliance
Protecting your grain means protecting the steel from within and without. We specify materials based on rigorous corrosion and safety standards:
- High-Strength Galvanized Steel: The outer shell uses G90 hot-dip galvanized steel (minimum 275 g/m² zinc coating). This provides a proven service life of 30+ years under normal inland agricultural atmospheres, verified by ASTM B117 salt spray testing.
- Food-Grade Epoxy Lining: To prevent metallic migration and internal condensation, the entire inner surface is coated with FDA-compliant epoxy resin (250–300 μm DFT), meeting EU 1935/2004 and FDA CFR 21 food contact regulations.
- Reinforced Structural Ring Beams: External stiffeners and ring beams are strategically welded to counteract buckling forces from lateral earth pressure and wind suction.
Application Fields
Agricultural Farms:
For on-site storage of harvested grains to reduce transportation costs.
Grain Processing Factories:
As intermediate storage for raw materials and finished products.
Agricultural Cooperatives:
For centralized storage of grains collected from smallholder farmers.
Feed Production Plants:
To store bulk grains used as feed ingredients.
Precision Fabrication & Quality Control
Our manufacturing process ensures workshop-level quality, even for field-assembled components:
- CNC Profile Cutting & Rolling: Steel plates are laser-cut and rolled into precise curved segments using CNC machinery, ensuring perfect bolt-hole alignment.
- Automated Welding & Drilling: Reinforcement ribs and flange plates are automatically welded. All bolt holes are drilled in jigs to maintain ±1mm tolerances.
- High-Temp Curing Coating: Food-grade epoxy is applied via airless spray and heat-cured at 180°C to form a cross-linked, non-toxic film.
- Pre-Shipment Inspection: Every segment undergoes a Final Quality Acceptance (FQA) check, including coating thickness tests (Elcometer).
Frequently Asked Questions (FAQ)
